Inconel Chemical Etching

E-Fab Materials Iconcel Bar

Picking a metal that can withstand several compromising environments is crucial for part dependability and longevity. Inconel is a material that offers impressive strength, elemental resistance, and flexibility.

E-Fab customers ask us to manufacture precision parts from Inconel for industrial, aerospace, electronics, and green energy applications.

We welcome your questions about how to use Inconel for your parts.

Type of Inconel We Use

Inconel is available in a few different grades, each offering unique benefits for the manufacture of precision metal parts.

Here are the most common types of Inconel we use:

600   601

Call us to discuss which alloy is right for your part.

Inconel Etching Capabilities

Panel SizeMin. 6” x 6”, max. 12” x 18”
Panel ThicknessMin. 0.001”, max. 0.030”
Hole SizeMin. 0.006” or 125% of material thickness
SpacingMin. same as material thickness
Inside & Outside RadiiInside: Approx. 80% material thickness Outside: Material thickness
Center-center hole distanceDIA + material thickness
Etch Tolerance± 20% material thickness, no less than ±0.001”

Why Choose Inconel

High Tensile Strength
Corrosion Resistance
Temperature Flexibility
Environmental Resistance
Inconel 600 and Inconel 601 are metals suited for the most challenging environments, including high temperatures and installations where acid and chloride stress exists. The material is flexible enough for the photochemical etching of precision parts and strong enough for reliability and longevity.

E-Fab manufacturers are experts at etching and forming inconel to precise standards and specifications.

The flexibility and strength of Inconel make it a great choice for electron shields, high-strength control valves, mesh screens, and other precision parts used in the aerospace, electronics, and green energy industries.

E-Fab is an industry leader in delivering innovative, accurate, and reliable parts thanks to decades of experience and expertise in a suite of processes.

We are known for our experience and expertise in:

R&D
Engineering
Design Support
Photochemical Etching

Forming
Bonding
High-frequency Substrate CNC Machining

Deburring
Micromachining
Prototype
Supply Chain Acquisitions

We work with the world’s most important industries.

E-fab Aerospace
Aerospace
E-fab Industries Defense Army Tank
Defense
Eye Examination Test
Medical
E-fab Industries Technology
Electronics
Energy
E-fab Telecom Ground Satelite
Telecommunications
Containing Fuel in Auto Tank
Electr. Vehicles & Automotive

Contact us to discuss how we can deliver engineering and manufacturing solutions.
