Chemical Etching with Tungsten

Tungsten is a refractory metal with the highest melting point of 3422°C among all other known elements, which makes it suitable for applications that operate in extremely high temperatures.

In addition to its exceptional melting point, its high tensile strength and high density make tungsten an ideal material for various applications, such as manufacturing surgical tools, electron guns, X-ray tubes, and radiation shields. Tungsten’s unique properties ensure reliable performance and durability for the devices manufactured using the metal.

We welcome your questions about how to use Tungsten for your parts.

Tungsten is a refractory metal with an incredibly high melting point (3422°C) among all other known elements, which makes it ideal for applications in extremely high temperatures.

Etching many grades of tungsten, including high-purity, copper-tungsten, tungsten-rhenium, thoriated rhenium, and AKS-grade

Call us to discuss which Tungsten alloy is right for your part.

Tungsten Etching Capabilities

Panel Size	Min. 4"x6", max. 14"x20"
Panel Thickness	Min. 0.001”, max 0.040”
Hole Size	Min. 0.005” or 1.2x of material thickness
Spacing	Min. same as material thickness
Inside & Outside Radii	Min. same as material thickness
Center-center hole distance	Refer to hole size and minimum spacing requirements
Etch Tolerance	minimum of ± .0005”; increase minimum based on material thickness and feature type

Why Choose
Tungsten

High melting point
Radiation shielding
Chemical stability
Hardness and durability

Choosing tungsten for manufacturing offers a compelling array of advantages. Its exceptional hardness, high melting point, and corrosion resistance make it ideal for creating durable tools and components that withstand harsh conditions.

E-Fab manufacturers are experts at etching and forming tungsten to precise standards and specifications.

Customers select tungsten for surgical tools, electron guns, X-ray tubes, and radiation shields. E-Fab delivers precision titanium parts for aerospace, semiconductor, and microelectronics companies.

E-Fab is an industry leader in delivering innovative, accurate, and reliable parts thanks to decades of experience and expertise in a suite of processes.

We are known for our experience and expertise in:

R&D

Engineering

Design Support

Photochemical Etching

Forming

Bonding

High-frequency Substrate

CNC Machining

Plating

Deburring

Micromachining

Prototype

Supply Chain Acquisitions

We work with the world’s most important industries.

Contact us to discuss how we can deliver engineering and manufacturing solutions.

We are

We are an expert team of engineers, manufacturers, and quality assurance specialists that deliver precision parts with ultimate accuracy. We serve technology companies, defense contractors, medical equipment manufacturers, and innovators from our Santa Clara, California headquarters.
